One device to connect them all



Easily configurable through the Darkglass Suite, the Darkglass MIDI Footswitch offers customizable MIDI commands at the tips of your toes. The MIDI footswitch is quick to set up with ready-to-use templates for Darkglass products. A more complex custom MIDI setup is also available with commands on the main and sub operational layers, simultaneous sending of several messages and more, making it a powerful command center that integrates seamlessly with your setup.

The MIDI footswitch can be powered flexibly through either a 9V DC or USB. In addition, the Darkglass amplifiers are capable of powering it through the same 1/4″ plug or a 7-PIN MIDI connector used for the data, offering the full operation using only one cable.

Darkglass Suite

The Darkglass Suite maximizes the capabilities of the MIDI Footswitch, offering an interface to configure and interact with it for use with Darkglass Devices or as a generic MIDI device.

Input & Outputs

MIDI OUT/THRU

7/5-pin DIN connector

  • Connects to Darkglass amplifiers or pedals that have a MIDI IN connection.
  • When connected to a Darkglass e500 or Infinity Combo amplifiers with a 7-pin MIDI cable no external power supply is required.
  • Can be used with 5-pin MIDI cable for connecting to any other generic MIDI device.

MIDI IN

5-pin DIN connector

  • Connects to a MIDI OUT on another MIDI device
  • Passes the MIDI messages through to MIDI OUT/THRU connector.

USB

USB-C connector

  • Connects to a computer for setting the configuration using Darkglass Suite.
  • Can be directly connected to Darkglass e500 amplifier for syncing settings.
  • USB power banks and chargers can be used as the power source for the footswitch.



9V DC

Barrel jack connector (center negative)

  • Can be powered with a generic power supply.

Darkglass Amplifier

1⁄4” TS jack connector

Connects to FOOTSWITCH connector of Darkglass amplifiers.

  • Works as a Darkglass Super Intelligent Footswitch.
  • When used as Super Intelligent Footswitch no external power supply is required.

Dimensions

Width: 276 mm / 10.8″
Length: 54 mm/ 3.1″
Height: 54.6 mm / 2.1″
Weight: 150 g / 0.33 lb

Warning

The MIDI Footswitch has a current draw of 15mA. Only use a regulated 9V DC adapter with a center-negative plug.

Unregulated power supplies and/or higher voltages may result in suboptimal noise performance and even damage your unit, voiding the warranty.

Disclaimer

In the interest of continuous improvement, specifications are subject to change without notice. If you have any questions, please don’t hesitate to contact us at www.darkglass.com

The manufacturer claims that the above product fulfills the requirements as set by EN55013, EN55020, EN60555-2, EN60555-3, RoHS, WEEE.
